Keithley 2002

Replaceable Parts
4-13
Table 4-5
Model 2002 miscellaneous, parts list
Circuit desig. Description
Keithley part
number
J1001
J1003, 1005, 1014, 1016
J1004, 1006, 1013, 1015
J1012
P1002
P1037
1/4X1/4X.2 PAD, THERMAL
BANANA JACK, PUSH-IN, BLACK
BANANA JACK, PUSH-IN, RED
BEZEL, REAR
CHASSIS
CHOKE
COVER
DISK PROGRAMMING
DISPLAY LENS
DISPLAY SHIELD
FAN, DC BRUSHLESS, 12VDC, 100MA
FILTER, FAN
FOOT
FOOT, EXTRUDED
FOOT, RUBBER
FRONT/REAR SWITCH ROD
FUSE, 2A, 250V, FAST-BLO(5X20MM)
HANDLE
LEXAN, ANALOG BOTTOM SHIELD
LEXAN, SHIELD, CHASSIS-RIGHT
MOUNTING EAR, LEFT
MOUNTING EAR, RIGHT
POWER ROD
PRINTED, FRONT PANEL
SHIELD
SHIELDED, ANALOG BOTTOM SHIELD
SHIELDED, ANALOG TOP SHIELD
TRANSFORMER
CONN, AC RECEPTACLE (LINE FILTER)
BANANA JACK, PUSH-IN, RED
BANANA JACK, PUSH-IN, BLACK
BANANA JACK, PUSH-IN, WHITE
CONN, MOLEX HEADER
CONNECTOR, HOUSING
HS-46A
BJ-13-0
BJ-13-2
428-303D
2001-303
CH-58-1A
2001-360C
2002-DSK-81
2002-305C
2001-304
FN-26
2001-353C
428-319A
FE-22A
FE-6
2001-322A
FU-48
428-329F
2001-340B
2001-336B
428-338B
428-328E
2001-320A
2001-356C
2002-325A
2001-339C
2002-324A
TR-280D
LF-6-1
BJ-13-2
BJ-13-0
BJ-13-9
CS-716-3
CS-638-3
