Keithley 2110-100 User Manual

Model 2110
5½ Digit Multimeter Reference Manual Section 3:
Basic DMM operation
2110-901-01 Rev. C/August 2013 3-43
Remote operation
Commands that use the <n> parameter can use the MINimum and MAXimum name parameters. MIN
selects the minimum value and MAX selects the maximum value.
Use the following commands to set the integration time:
VOLTage[:DC]:NPLCycles <n>
Set integration time for DCV
CURRent[:DC]:NPLCycles <n>
Set integration time for DCI
RESistance:NPLCycles <n>
Set integration time for
Ω
2
FRESistance:NPLCycles <n>
Set integration time for
Ω4
<n> = 0.001 to 100
Number of power line cycles (NPLC)
Use the following commands to set resolution:
VOLTage[:DC]:RESolution <n>
Set resolution for DCV
CURRent[:DC]:RESolution <n>
Set resolution for DCI
RESistance:RESolution <n>
Set resolution for
Ω
2
FRESistance:RESolution <n>
Set resolution for
Ω4
<n> = (See note)
Measurement resolution
The resolution setting range for <resolution> depends on the selected function and range. The
maximum value for DC measurement is 3.00e-04 x full-scale range, and the minimum value is
3.00e-07 x full-scale range. For example, for DCV 1000 V range, the minimum value is (3.00e-07 x
1000 V = 3.00e-04). The maximum value is (3.00e-04 x 1000 V = 3.00e-01). Therefore, <resolution>
= 3.00e-04 to 3.00e-01 for the DCV 1000 V range.
For example, for DCI 10 A range, the minimum value is (3.00e-07 x 10 A = 3.00e-06). The maximum
value is (3.00e-04 x 10 A = 3.00e-03). Therefore, <resolution> = 3.00e-06 to 3.00e-03 for the DCI
10 A range.
For example, for Ω2 and Ω4 1.00e+08 Ω range, the minimum value is (3e-07 x 1.00e+08 Ω = 30).
The maximum value is (3.00e-04 x 1.00e+08 Ω = 3.00e+04). Therefore, <resolution> = 30 to
3.00e+04 for the Ω2 and Ω4 1.00e+08 Ω range.
