Keithley 2701 Instruction Manual

Model 2701 Instrument Networking Instruction Manual Configuring TCP/IP addresses 3-3
Use Table 3-1 as a quick reference guide for the IS/IT department. Please refer to the appro-
priate sections of the this manual as well as the Model 2701 User’s Manual for detailed expla-
nations of the information below.
To set the Model 2701 to use DHCP from the front panel:
Press SHIFT->ETHERNET->VIEW
Dashes will be displayed for Address, Subnet, and Gateway until the unit gets them from the
DHCP server.
To set the Model 2701 to use DHCP over the Ethernet, use the internal web page (refer to
“Check or set TCP/IP address over Ethernet” on page 3-8).
Table 3-1
IT/IS department quick reference guide
Network resource Action Description
MAC address View Different methods can be used to perform the action
listed for each network resource (e.g., use the inter
-
nal web page or the front panel). SCPI commands
can also be used to perform the action on each
resource (refer to the Model 2701 User’s Manual for
further information on SCPI programming).
IP address View/Set
Subset Mask View/Set
Default Gateway View/Set
DHCP On/Off
DNS N.A. Not Supported.
Number of
2701connections
1 The 2701 will only support a single connection to the
instrument at a time.

Keithley 2701 Specifications

General

Max Voltage	300 V
Max Current	3 A
Frequency Range	3 Hz to 500 kHz
Frequency Accuracy	0.01%
Weight	3.6 kg
Measurement Functions	Frequency, Temperature
Interface	IEEE-488 (GPIB), RS-232
DC Voltage Range	300 V
DC Current Range	3 A
AC Voltage Range	300V
AC Current Range	1 μA to 3 A
Resistance Accuracy	0.01%
Channels	10
Dimensions	213mm x 88mm x 370mm
