6-4 Replaceable Parts Model 2750 Multimeter/Switch System Service Manual
C171,C177 CAP, 2200P, 10%, 100V, CERAMIC C-430-2200P
C175,C209 CAP, 22UF, 20%, 25V, TANTALUM C-440-22
C179,C266 CAP, 100PF, 5%, 100V, CERAMIC C-465-100P
C182-C185,C187,C190,C193,
C194,C197-C199
CAP, .1UF, 20%, 50V, CERAMIC C-418-.1
C186,C189,C191 CAP, .01UF, 20%, 50V, CERAMIC C-418-.01
C188 CAP, 10PF, 5%, 50V, MONO CERAMIC C-452-10P
C201-C208,C210,C212-C218,
C221,C223,C225
CAP, .1UF, 20%, 50V, CERAMIC C-418-.1
C220,C222,C255-
C262,C268,C303-C311
CAP, 47P, 5%, 100V, CERAMIC C-465-47P
C227,C229,C231-C234,C236-
C239,C250,C263
CAP, .1UF, 20%, 50V, CERAMIC C-418-.1
C230,C296 CAP, .01UF, 20%, 50V, CERAMIC C-418-.01
C242,C243,C246,C249,C283,C284 CAP, .01UF, 10%, 50V, CERAMIC C-491-.01
C244,C267,C272,C278 CAP, 1000PF, 20%, 50V, CERAMIC C-418-1000P
C252 CAP, 22PF, 10%, 100V, CERAMIC C-451-22P
C264,C265,C291,C292 CAP, 15P, 1%, 100V, CERAMIC C-512-15P
C269-C271,C275,C276,C279,
C298,C299,C149
CAP, .1UF, 20%, 50V, CERAMIC C-418-.1
C293,C294 CAP, 47UF, +/-20%, 25V, ALUM ELEC C-314-47
C297,C302 CAP, .1UF, 20%, 50V, CERAMIC C-418-.1
C300,C301 CAP, 270PF, 5%, 100V, CERAMIC C-465-270P
CR102,CR103 DIODE, BRIDGE, DF01 RF-52
CR104,CR106 DIODE, BRIDGE, PE05 RF-48
CR105 DIODE, HI-VOLTAGE, HV-15 RF-76
CR107-CR109,CR111,CR112,
CR115-CR117
DIODE, DUAL SWITCHING, BAV99L RF-82
CR110,CR118 DIODE, DUAL, HSM-2822T31 RF-95
CR119 DIODE, SWITCHING, MMBD914 RF-83
CR120,CR122,CR125 DIODE, DUAL COMMON ANODE,
BAW56LT2
RF-98
CR126,CR101,CR113,CR114 DIODE, DUAL SWITCHING, BAV99L RF-82
DS101,DS102 PILOT LIG, HSMH-T400, LED PL-92-1
J1002 CONN, RT ANGLE HEADER CS-1017-1
J1003 CONN, RT ANGLE HEADER, 5 PINS CS-1017-2
J1004 CONN, RIGHT ANGLE, 24PIN CS-507
J1005 CONN, RT ANGLE, MALE, 9 PIN CS-761-9
J1006 CONN, MICRODIN W/GND FINGERS CS-792
J1007 CONN, D-SUB MALE, BOARDLOCK TYPE CS-848-9
Table 6-1 (continued)
Model 2750 motherboard parts list
Circuit Designation Description Keithley Part No.
