B-8 Calibration Reference Model 2750 Multimeter/Switch System Service Manual
DC calibration commands
The :DC commands perform calibration of the DCV, DCI, and ohms functions. Table B-2
summarizes these calibration commands along with parameter limits.
:STEP1
(:CALibration:PROTected:DC:STEP1)
Purpose To perform front terminal short-circuit calibration.
Format :cal:prot:dc:step1
Parameters None
Description :STEP1 performs the short-circuit calibration step in the comprehen-
sive calibration procedure. Connect a low-thermal short (Model 8610)
to the front panel input jacks before sending this command.
Example :CAL:PROT:DC:STEP1 Perform short-circuit calibration.
Tab le B- 2
DC calibration commands
Command Description Parameter Limits
:CALibration
:PROTected
:DC
:STEP1 Front terminal short circuit.
:STEP2 Open circuit.
:STEP3 <NRf> 10V DC calibration step. 9 to 11
:STEP4 <NRf> -10V DC calibration step. -9 to -11
:STEP5 <NRf> 100V DC calibration step. 90 to 110
:STEP6 <NRf> 100 4-wire calibration step. 90 to 110
:STEP7 <NRf> 10k 4-wire calibration step. 9E3 to 11E3
:STEP8 <NRf> 100k 4-wire calibration step. 90E3 to 110E3
:STEP9 <NRf> 1M 4-wire calibration step. 900E3 to 1.1E6
:STEP10 <NRf> 10mA DC calibration step. 9E-3 to 11E-3
:STEP11 <NRf> 100mA DC calibration step. 90E-3 to 110E-3
:STEP12 <NRf> 1A DC calibration step. 0.9 to 1.1

Keithley 2750 Specifications

General

Interface	GPIB, RS-232, Ethernet
Switching Speed	Up to 500 channels/second
Maximum Voltage	300V
Operating Temperature	0°C to 50°C
Measurement Functions	DCV, ACV, DCI, ACI, 2-wire Resistance, 4-wire Resistance, Frequency, Temperature
Resolution	6.5 digits
Current	1A
Maximum Current	1A
