6-14 Replaceable Parts Model 2750 Multimeter/Switch System Service Manual
Tab le 6- 4
Model 2750 miscellaneous parts list
Qty. Description Keithley Part No.
1 3 SLOT CARD CAGE 2750-316B
1 5X20MM SNAP-IN FUSE HOLDER FH-40
2 BANANA JACK, PUSH-IN, BLACK BJ-14-0
2 BANANA JACK, PUSH-IN, RED BJ-14-2
1 BANANA JACK, PUSH-IN, WHITE BJ-14-9
1 CARD CAGE 2700-318A
1 CARD CAGE SUPPORT 2750-313A
1 COND. RUBBER SWITCH 2750-310A
37 CONNECTOR CS-236
4 CONNECTOR CS-638-8
1 CONNECTOR, HARDWARE KIT CS-713
4 CONNECTOR, HOUSING CS-638-3
1 CONNECTOR, MODULES CS-638-12
1 COVER 2750-309A
1 DISPLAY LENS 2750-307A
4 FOOT MOLDED 24322
4 FOOT, RUBBER FE-6
1 FRONT PANEL 2750-305A
1 FRONT/REAR ROD 2700-319A
1 FUSE HOLDER FH-35-1
1 FUSE, .630A, 250V, SLO BLO FUSE FU-106-.630
1 FUSE, 3A, 250 FU-99-1
2 HANDLE HH-30-7
1 LINE CORD CO-7
1 LINE MODULE PM-1-1B
1 MOTHER BD SUPPORT BRACKET 2750-314A
1 POWER ROD 704-313A
1 REAR PANEL 2750-303A
1 RUBBER GROMMET GR-55-1
4 SCREWLOCK, FEMALE CS-725
5 SOCKET CONNECTOR CS-984-1
1 TEST LEADS CA-22
1 TILT BAIL 2750-319A
1 TRANSFORMER TR-347A

Keithley 2750 Specifications

General

Interface	GPIB, RS-232, Ethernet
Switching Speed	Up to 500 channels/second
Maximum Voltage	300V
Operating Temperature	0°C to 50°C
Measurement Functions	DCV, ACV, DCI, ACI, 2-wire Resistance, 4-wire Resistance, Frequency, Temperature
Resolution	6.5 digits
Current	1A
Maximum Current	1A
