System Switch/Multimeter User's Manual Section 3:
-900-01 Rev. A / August 2007 3-
2. rawsocket is 5025 (ICL: lan.status.port.rawsocket)
3. vxi11 is 1024 (ICL: lan.status.port.vxi11)
4. dead socket termination is 5030 (ICL: lan.status.port.dst)
When changing between the various bus interfaces, send the abort command to have that
interface become the active one for receiving and processing bus commands. For example, if
changing from communicating with instrument over GPIB and to send ICLs with a telnet session
(assuming both interfaces are enabled):
1. Connect via telnet.
2. Send abort to leave the GPIB interface and switch over to telnet.
3. Send commands as desired.
Any of the enable settings will take effect the next time the unit powers up. Therefore, after
making changes to these settings, power cycle the unit.
Power-up
Line power connection
Follow the procedure below to connect the Series 3700 to line power and turn on the instrument.
The Series 3700 operates from a line voltage of 100V to 240V at a frequency of 50Hz or 60Hz.
Line voltage is automatically sensed. There are no switches to set. Make sure the operating
voltage in your area is compatible.
WARNING The power cord supplied with the Series 3700 contains a separate ground
wire for use with grounded outlets. When proper connections are made,
instrument chassis is connected to power line ground through the ground
wire in the power cord. Failure to use a grounded outlet may result in
personal injury or death due to electric shock.
CAUTION Operating the instrument on an incorrect line voltage may cause damage to the
instrument, possibly voiding the warranty.
1. Before plugging in the power cord, make sure that the front panel power switch is in the off
(O) position. See Rear panel summary (on page 3-1) for connector location.
2. Connect the female end of the supplied power cord to the (5) Power Connector (AC
receptacle) on the rear panel. Connect the other end of the power cord to a grounded AC
outlet.
