Keithley 6517A User Manual

IEEE-488 Reference
3-49
:RESistance
:APERture <n>
:AUTO <b>
:AUTO ONCE
:AUTO?
:APERture?
:NPLCycles <n>
:AUTO <b>
:AUTO ONCE
:AUTO?
:NPLCycles?
[:AUTO]
:RANGe
[:UPPer] <n>
[:UPPer]?
:AUTO <b>
:AUTO ONCE
:ULIMit <n>
:ULIMit?
:LLIMit <n>
:LLIMit?
:AUTO?
:MANual
:CRANge
[:UPPer] <n>
[:UPPer]?
:AUTO <b>
:AUTO ONCE
:AUTO?
:VSOurce
[:AMPLitude] <n>
[:AMPLitude]?
:RANGe <n>
:RANGe?
:OPERate <b>
:OPERate?
:REFerence <n>
:STATe <b>
:STATe?
:ACQuire
:REFerence?
:IREFerence <b>
:IREFerence?
:DIGits <n>
:AUTO <b>
:AUTO ONCE
:AUTO?
:DIGits?
Path to configure resistance:
Set integration rate in seconds (166.67e-6 to 200e-3).
Enable or disable auto aperture.
Enable and then disable auto aperture.
Query auto aperture.
Query aperture.
Set integration rate (line cycles; 0.01 to 10).
Enable or disable auto NPLC.
Enable and then disable auto NPLC.
Query auto line cycle integration.
Query line cycle integration rate.
Path to configure Auto V-Source ohms.
Measurement ranges:
Select range (0 to 100e18).
Query range.
Enable or disable auto range.
Set range based on present input signal.
Set upper limit for auto range (0 to 100e18)
Query upper limit.
Set lower limit for auto range (0 to 100e18).
Query lower limit.
Query auto range.
Path to configure Manual V-Source ohms:
Path to configure measurement range:
Select range (0 to 21e-3).
Query range.
Enable or disable auto range.
Set range based on present input signal.
Query auto range.
Path to control the V-Source:
Specify V-Source level (0 to 1000V).
Query V-Source level.
Select V-Source range; ≤100 selects 100V range, >100
selects 1000V range.
Query V-Source range.
Enable (operate) or disable (standby) V-Source output.
Query state of V-Source.
Specify ohms reference (-100e18 to +100e18).
Enable or disable ohms reference.
Query state of ohms reference.
Use input signal as ohms reference.
Query ohms reference value.
Enable or disable amps reference.
Query state of amps reference.
Specify measurement resolution (4 to 7).
Enable or disable auto resolution.
Enable and then disable auto resolution.
Query auto resolution.
Query resolution.
(Note 1)
OFF
1
OFF
2e6
(Note 4)
200e12
2e6
20e-3
(Note 4)
0
100
OFF
0
OFF
6
√
√
√
√
√
√
√
√
√
3.18.4
3.18.5
3.19.6
3.19.6
3.18.7
3.19.8
3.18.9
Table 3-10 (Continued)
SENSe command summary
Command Description
Default
parameter SCPI Ref.
