3: Using a remote interface DMM6500 6½ Digit Multimeter
3-12 DMM6500-900-01Rev. A / April 2018
Set the GPIB address
Set the GPIB address. The default GPIB address is 16. You can set the address from one to 30 if it is
unique in the system. This address cannot conflict with an address that is assigned to another
instrument or to the GPIB controller.
GPIB controllers are usually set to 0 or 21. To be safe, do not configure any instrument to have an
address of 21.
The instrument saves the address in nonvolatile memory. It does not change when you send a reset
command or when you turn the power off and on again.
To set the GPIB address from the front panel:
1. Press the MENU key.
2. Select Communication.
3. Select the GPIB tab.
4. Set the GPIB address.
5. Select OK.
You can also set the GPIB address using remote commands. Set the GPIB address with the SCPI
command :SYSTem:GPIB:ADDRess or the TSP command gpib.address.
RS-232
Install the KTTI-RS232 accessory card
Unpack and inspect
Make sure to handle the KTTI-RS232 carefully. Always grasp the card by the side edges. Do not
touch board surfaces, components, or areas adjacent to electrical contacts. Contamination from
foreign materials such as dirt, dust, and body oils can substantially degrade card performance.
To unpack and inspect your instrument:
1. Inspect the box for damage.
2. Open the box.
3. Remove the card and inspect for any obvious signs of physical damage.
4. Report any damage to the shipping agent immediately.
Installation
Slot covers must be installed on unused slots to prevent personal contact with high-voltage
circuits. Failure to recognize and observe standard safety precautions could result in
personal injury or death due to electric shock.
