6-2 Range, Digits, Speed, Rel, and Filters Series 2600 System SourceMeters Reference Manual
2600S-901-01 Rev. A / May 2006 Return to Section 6 topics
Overview
The documentation in this section provides detailed information on characteristics
and script programming for each of the following functions:
• Range
• Digits
• Speed
• Rel
• Filters
Range
The selected measurement range affects the accuracy of the measurements as
well as the maximum signal that can be measured. Note that dashed lines are
displayed (i.e., --.---- µA), to indicate that the previous measurement is not recent.
This usually happens when a change occurs such as selecting a different range.
Available ranges
Table 6-1 lists the available source and measurement ranges for the Series 2600
SourceMeters.
Table 6-1
Source and measurement ranges
Model 2601/2602 Model 2611/2612
Voltage Ranges Current Ranges Voltage Ranges Current Ranges
100mV
1V
6V
40V
100nA
1μA
10μΑ
100μΑ
1mA
10mA
100mA
1A
3A
200mV
2V
20V
200V
100nA
1μA
10μΑ
100μΑ
1mA
10mA
100mA
1A
1.5A
10A
1
1. 10A range available only in pulse mode.
