Series 2600 System SourceMeters Reference Manual Performance Verification 15-13
Return to Section 15 topics 2600S-901-01 Rev. A / May 2006
Figure 15-2
Current verification connections
WARNING:
NO INTERNAL OPERATOR SERVICABLE PARTS,SERVICE BY QUALIFIED PERSONNEL ONLY.
WARNING:
NO INTERNAL OPERATOR SERVICABLE PARTS,SERVICE BY QUALIFIED PERSONNEL ONLY.
CAUTION:
FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,REPLACE FUSE WITH SAME TYPE AND RATING.
CAUTION:
FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,REPLACE FUSE WITH SAME TYPE AND RATING.
MADE IN
U.S.A.
IEEE-488
(CHANGE IEEE ADDRESS
WITH FRONT PANEL MENU)
LINE RATING
100-240VAC
50, 60Hz
240VA MAX.
DIGITAL I/O
RS-232
TSP-Link
LINE FUSE
SLOWBLOW
3.15A, 250V
CAT I
SS
LO LO HIHI GGGG
CHANNEL A
!
!
!
U
L
C
US
LISTED
SourceMeter
4ZA4
CAT I
S
S
LO
LO
HI
HI
G
G
G
G
CHANNEL B
!
R
Digital Multimeter
Amps
Input LO
Model 2602/2612 Channel A
Connections Shown
LO
HI
(100nA to 1A ranges)
Table 15-6
Model 2601/2602 output current accuracy limits
Model
2601/2602
source range
Model 2601/2602
output
current setting
Output current limits
(1 year, 18°C–28°C)
100nA
1µA
10µA
100µA
1mA
10mA
100mA
1A
3A
90.000nA
0.90000µA
9.0000µA
90.000µA
0.90000mA
9.0000mA
90.000mA
0.90000A
2.40000A
89.846 to 90.154nA
0.89913 to 0.90087µA
8.9953 to 9.0047µA
89.943 to 90.057µA
0.89953 to 0.90047mA
8.9943 to 9.0057mA
89.953 to 90.047mA
0.89865 to 0.90135A
2.39706 to 2.40294A
