15-14 Performance Verification Series 2600 System SourceMeters Reference Manual
2600S-901-01 Rev. A / May 2006 Return to Section 15 topics
Figure 15-3
Current verification connections
WARNING: NO INTERNAL OPERATOR SERVICABLE PARTS,SERVICE BY QUALIFIED PERSONNEL ONLY.
WARNING: NO INTERNAL OPERATOR SERVICABLE PARTS,SERVICE BY QUALIFIED PERSONNEL ONLY.
CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,REPLACE FUSE WITH SAME TYPE AND RATING.
CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,REPLACE FUSE WITH SAME TYPE AND RATING.
MADE IN
U.S.A.
IEEE-488
(CHANGE IEEE ADDRESS
WITH FRONT PANEL MENU)
LINE RATING
100-240VAC
50, 60Hz
240VA MAX.
DIGITAL I/O
RS-232
TSP-Link
LINE FUSE
SLOWBLOW
3.15A, 250V
CAT I
SS
LO LO HIHI GGGG
CHANNEL A
!
!
!
U
L
C
US
LISTED
SourceMeter
4ZA4
CAT I
S
S
LO
LO
HI
HI
G
G
G
G
CHANNEL B
!
R
Digital Multimeter
Input HI
Input LO
Model 2602/2612 Channel A
Connections Shown
LO
HI
0.5W
250W
Resistor
Sense
Terminals
Load
Terminals
(2601/2602 3A range; 2611/2612 1.5A range)
Table 15-7
Model 2611/2612 output current accuracy limits
Model
2611/2612
source range
Model 2611/2612
output
current setting
Output current limits
(1 year, 18°C–28°C)
100nA
1µA
10µA
100µA
1mA
10mA
100mA
1A
1.5A
10A
90.000nA
0.90000µA
9.0000µA
90.000µA
0.90000mA
9.0000mA
90.000mA
0.90000A
1.35000A
9.00000A
89.846 to 90.154nA
0.89893 to 0.90107µA
8.9923 to 9.0077µA
89.913 to 90.087µA
0.89943 to 0.90057mA
8.9913 to 9.0087mA
89.943 to 90.057mA
0.89775 to 0.90225A
1.34519 to 1.35481A
8.958 to 9.042A
