Table D-6
Status event status registers and bits
Command Bit
To set register bits:
status.standard.enable = status.standard.OPERATION_COMPLETE
status.standard.enable = status.standard.OPC
status.standard.enable = status.standard.QUERY_ERROR
status.standard.enable = status.standard.QYE
status.standard.enable = status.standard.DEVICE_DEPENDENT_ERROR
status.standard.enable = status.standard.DDE
status.standard.enable = status.standard.EXECUTION_ERROR
status.standard.enable = status.standard.EXE
status.standard.enable = status.standard.COMMAND_ERROR
status.standard.enable = status.standard.CME
status.standard.enable = status.standard.USER_REQUEST
status.standard.enable = status.standard.URQ
status.standard.enable = status.standard.POWER_ON
status.standard.enable = status.standard.PON
To read registers:
print(status.standard.enable)
print(status.standard.condition)
print(status.standard.event)
B0
B0
B2
B2
B3
B3
B4
B4
B5
B5
B6
B6
B7
B7
D-20 Status Model Series 2600 System SourceMeters Reference Manual
2600S-901-01 Rev. A / May 2006 Return to Appendix D topics
Operation Event Registers
As shown in Figure D-3, there are seven register sets associated with Operation
Event Status. Commands are summarized in Table D-7. Keep in mind that bits
can also be set by using numeric parameter values. For details, see “Program-
ming enable and transition registers” in this appendix.
For example, either of the following commands will set the CAL enable bit (B0):
status.operation.enable = status.operation.CAL
status.operation.enable = 1
When reading a register, a numeric value is returned. The binary equivalent of this
value indicates which bits in the register are set. For details, see “
Reading regis-
ters” in this appendix. For example, the following command will read the operation
enable register:
print(status.operation.enable)
Operation Status Register
This register set feeds to bit B7 (OSB) of the Status Byte. The bits used in the
Operation Status Register set are described as follows:
