D-30 Status Model Series 2600 System SourceMeters Reference Manual
2600S-901-01 Rev. A / May 2006 Return to Appendix D topics
Table D-9
Measurement event commands
Command
1
Bit
To set register bits:
status.measurement.* = status.measurement.VOLTAGE_LIMIT
status.measurement.* = status.measurement.VLMT
status.measurement.* = status.measurement.CURRENT_LIMIT
status.measurement.* = status.measurement.ILMT
status.measurement.* = status.measurement.READING_OVERFLOW
status.measurement.* = status.measurement.ROF
status.measurement.* = status.measurement.BUFFER_AVAILABLE
status.measurement.* = status.measurement.BAV
status.measurement.* = status.measurement.OUTPUT_ENABLE
status.measurement.* = status.measurement.OE
status.measurement.* = status.measurement.INSTRUMENT_SUMMARY
status.measurement.* = status.measurement.INST
To read registers:
print(status.measurement.*)
print(status.measurement.condition)
print(status.measurement.event)
B0
B0
B1
B1
B7
B7
B8
B8
B11
B11
B13
B13
To set register bits:
status.measurement.instrument.smuX.* = status.measurement.VOLTAGE_LIMIT
status.measurement.instrument.smuX.* = status.measurement.VLMT
status.measurement.instrument.smuX.* = status.measurement.CURRENT_LIMIT
status.measurement.instrument.smuX.* = status.measurement.ILMT
status.measurement.instrument.smuX.* = status.measurement.READING_OVERFLOW
status.measurement.instrument.smuX.* = status.measurement.ROF
status.measurement.instrument.smuX.* = status.measurement.BUFFER_AVAILABLE
status.measurement.instrument.smuX.* = status.measurement.BAV
To read registers:
print(status.measurement.instrument.smuX.*)
print(status.measurement.instrument.smuX.condition)
print(status.measurement.instrument.smuX.event)
B0
B0
B1
B1
B7
B7
B8
B8
To set register bits:
status.measurement.instrument.* = status.measurement.instrument.SMUA
status.measurement.instrument.* = status.measurement.instrument.SMUB
To read registers:
print(status.measurement.instrument.*)
print(status.measurement.instrument.condition)
print(status.measurement.instrument.event)
B1
B2
1. * = '.ntr', '.ptr' and '.enable'; smuX = smua or smub.
