Series 2600 System SourceMeters Reference Manual Status Model D-31
Return to Appendix D topics 2600S-901-01 Rev. A / May 2006
To set register bits:
status.measurement.voltage_limit.* = status.measurement.voltage_limit.SMUA
status.measurement.voltage_limit.* = status.measurement.voltage_limit.SMUB
To read registers:
print(status.measurement.voltage_limit.*)
print(status.measurement.voltage_limit.condition)
print(status.measurement.voltage_limit.event)
B1
B2
To set register bits:
status.measurement.current_limit.* = status.measurement.current_limit.SMUA
status.measurement.current_limit.* = status.measurement.current_limit.SMUB
To read registers:
print(status.measurement.current_limit.*)
print(status.measurement.current_limit.condition)
print(status.measurement.current_limit.event)
B1
B2
To set register bits:
status.measurement.buffer_available.* = status.measurement.buffer_available.SMUA
status.measurement.buffer_available.* = status.measurement.buffer_available.SMUB
To read registers:
print(status.measurement.buffer_available.*)
print(status.measurement.buffer_available.condition)
print(status.measurement buffer_available.event)
B1
B2
To set register bits:
status.measurement.reading_overflow.* = status.measurement.reading_overflow.SMUA
status.measurement.reading_overflow.* = status.measurement.reading_overflow.SMUB
To read registers:
print(status.measurement.reading_overflow.*)
print(status.measurement.reading_overflow.condition)
print(status.measurement.reading_overflow.event)
B1
B2
Table D-9 (cont.)
Measurement event commands
Command
1
Bit
1. * = '.ntr', '.ptr' and '.enable'; smuX = smua or smub.
