Flexlite GX
Operating manual - EN
3.3 Connecting gun
Hand-tighten the gun connectors. Loose connectors may overheat, create contact disturbances, mechanical damage
and water or gas leakage.
For connecting the gun (and applicable extension parts), refer also to your welding equipment’s instructions.
If not already preinstalled, the wire liner must be installed before connecting the gun. Refer to "Replacing steel wire
liner" on page16 for instructions.
1. Connect the gun to your welding equipment. Secure the connector in place by turning the collar clockwise.
2. Water-cooled models only: Connect the coolant inlet and outlet hoses to your welding equipment. Note that the
connectors are color-coded.
Make sure to connect the coolant hoses to the correct hose connectors. If the connections cross, the welding gun
may overheat.
© Kemppi
11
1921390 / 2310
