Flexlite GX
Operating manual - EN
2. ABOUT EQUIPMENT
The Flexlite GX MIG welding gun equipment consists of:
The exact visual details may be different between different Flexlite GX models.
1. Gas nozzle
2. Contact tip
3. Contact tip adapter / gas diffuser
4. Gun neck
5. Handle
6. Trigger switch
7. Cover plate
>> This covers the handle if a welding gun remote is not used (Flexlite GX series 5 and series 8 models). For more
information on the gun remotes, refer to "Installing gun remote" on page9.
>> Not available with Flexlite GX series 3 models.
8. Gun connector
9. Coolant inlet and outlet hose connectors
>> With water-cooled welding guns only.
10. Neck tightening collar
>> With multi-neck welding guns only.
© Kemppi
5
1921390 / 2310
