Flexlite GX
Operating manual - EN
3.1 Assembling gun
For the correct components, refer to "Component selection" on page60.
Tools needed:
8mm
1. Attach the contact tip adapter and hand-tighten it firmly in place. It is important to tighten the adapter properly to
enable a tight connection of the contact tip to the gun.
2. Attach the contact tip and secure it with the 8 mm spanner.
3. Attach the gas nozzle and hand-tighten it firmly in place.
With multi-neck gun models only:
4. Attach the assembled neck to the gun body. Secure with the neck tightening collar.
Hand-tighten the neck tightening collar only. Over-tightening and/or using a tool can damage the gun components.
© Kemppi
8
1921390 / 2310
