Flexlite GX
Operating manual - EN
Settings diagram:
Primary (default) Secondary
ON ON ON ON
1 2 1 2
- Kemppi Fastmig
- Kempact Pulse
- Kemppi Pro
- Kempact Classic
- Fitweld
- X3 MIG Welder
- Kempact RA
- Other than Kemppi
Tools needed:
TX6
For changing the setting:
1. Detach the trigger switch. Refer to "Trigger switch replacement" on page24 for more detailed instructions.
2. Release the small screw holding the trigger switch circuit board and remove the circuit board.
3. Set the two dip switches on the circuit board to the correct position (refer to the settings diagram above).
