EN
2.5.2 Gas cooled system: KempArc Pulse + DT 400
1.
4.
6.
7.
2.
8.
3.
5.
1. DT 400 wire feed unit
2. KempArc Pulse power source
3. Gas supply
4. Gas cooled welding Gun
5. Power cable
6. Earth return lead and clamp
7. KF 62 remote panel (optional)
8. Robot controller
2.5.3 Connecting to mains power
KempArc power sources are delivered as standard with 5 meters of mains power cable. No
mains plug is tted at the Kemppi factory.
NOTE! If local country based regulations state an alternative power cable is required, the mains
cable must be replaced in conformity with the regulations. Connection and installation of the
mains cable and plug, should only be carried out by a suitably qualied person.
Remove the machine cover plate to enable mounting of a mains cable. KempArc Pulse power
sources can be connected to the mains supply of 400 V 3~ .
7
KempArc Pulse 350, 450 / © Kemppi Oy / 1044
