Kemppi Master M 205 User Manual

Master M 205, 323
Operating manual - EN
2.1 Installing power source mains plug
Only an authorized electrician is allowed to install the mains cable and plug.
Do not connect the machine to the mains before the installation is complete.
Install the mains plug according to the Master M device and site requirements. Refer also to "Technical data" on page63
for device specific technical information.
The mains cable includes the following wires:
1. Brown: L1
2. Black: L2
3. Grey: L3
4. Yellow-green: Protective earth
Cable type and fuse rating requirements:
Unit amperage Cable type Fuse rating
200 A (220-230 / 110-130 V)
2.5 mm
2
16 / 16 A
320 A (380-460 / 220-230 V)
2.5 mm
2
16 / 32 A
© Kemppi
10
1922130 / 2313
