Master M 205, 323
Operating manual - EN
1.1 Equipment description
Master M device models
• Master M 205 GM (200 A)
>> Generator-compatible and multi-voltage
>> Pulse device with automatic 1-MIG process (pulse welding with 220...240 V supply voltage only).
• Master M 323 GM (320 A)
>> Generator-compatible and multi-voltage
>> Standard device with automatic 1-MIG and MAX Cool process.
The Master M device models have a 2-roll wire feed mechanism. The maximum wire spool diameter is 200 mm.
For the Master M device part descriptions, refer to "Master M 205 and 323 devices" on the next page.
Master M cooling units
• Master Cooler 05M.
For the cooling unit part descriptions, refer to "Master Cooler 05M cooling unit (optional)" on page8.
MIG welding guns
• Flexlite GX welding guns with euro connector.
For more information on the Flexlite GX welding guns, refer to Kemppi Userdoc.
Welding programs
• Welding program work pack (factory-installed)
• Four welding programs for MAX Cool process in Master M 323 (factory-installed).
The welding programs included in the Master M work packs are shown here: "Welding program work packs" on page72.
Optional accessories
• 2-wheel carts
• Protection sliders
• Power source air filter
• Wire feed cabinet heater.
For more information on optional accessories, contact your local Kemppi dealer.
EQUIPMENT IDENTIFICATION
Serial number
Serial number of the device is marked on the rating plate or in another distinctive location on the device. It is
important to make correct reference to the serial number of the product when ordering spare parts or making
repairs for example.
Quick Response (QR) code
The serial number and other device-related identification information may also be saved in the form of a QR
code (or a barcode) on the device. Such code can be read by a smartphone camera or with a dedicated code
reader device providing fast access to the device-specific information.
© Kemppi
5
1922130 / 2313
