Master M 205, 323
Operating manual - EN
1.3 Master Cooler 05M cooling unit (optional)
The cooling unit is not available for Master M 205 with 110...130 V supply voltage.
Front
1. Front locking interface
>> For locking to the power source
2. Cooler container cap
3. Cooling liquid level indicator
4. Cooling liquid circulation button
>> Keeping the button pressed activates the pump and circulates the cooling liquid throughout the system. Once
released, the pump stops.
5. Front locking interface
>> For locking on the cart
6. Coolant inlet connector (red)
7. Coolant outlet connector (blue).
Rear
1. Rear locking interface
>> For locking to the power source
2. Rear locking interface
>> For locking on the cart.
© Kemppi
8
1922130 / 2313
