Master M 205, 323
Operating manual - EN
2.8 Installing and replacing feed rolls
Replace the feed rolls when the filler wire diameter or material changes. Select the feed rolls according to the tables in
"Wire feeder consumables" on page69.
1. Open the wire feed cabinet hatch.
2. Release the pressure handle.
3. Pull the pressure roll mounting pin and drive roll mounting cap off.
The pressure roll's mounting pin has a central axle attached to it, whereas the drive roll' s central axle act s as a drive
shaft attached directly to the wire feed mechanism/motor.
© Kemppi
26
1922130 / 2313
