Kemppi Master M 205 User Manual

Master M 205, 323
Operating manual - EN
4.6 Installing and cleaning power source air filter (optional)
An optional power source air filter can be purchased separately. The air filter comes with a fixed casing designed to be
mounted directly onto the power source air intake.
Using the optional air filter decreases the rated power levels of the power source as follows (output 40 °C):60% >>>
45% and 100% >>> 100%-20A. This is due to the slightly reduced cooling air intake.
Tools needed:
Installation and replacement
1. Place the air filter assembly onto the power source air intake, and lock it in place with the clips on the edge of the
casing.
Cleansing
1. Remove the air filter from the power source by releasing the clips on the edge of the air filter casing.
2. Blow the air filter clean with compressed air.
© Kemppi
61
1922130 / 2313

Kemppi Master M 205 Specifications

General

Brand	Kemppi
Model	Master M 205
Category	Welding System
Language	English
