Master M 205, 323
Operating manual - EN
2. Fix the cooling unit to the cart with two screws (M5x12) in the front.
3. Install the Master M device on top of the cooling unit. Refer to "Installing cooling unit (optional)" on page11 for
installation details.
4. Secure the transportation handle to the cart with an additional bracket and a screw (M8x16).
To install the Master M device on the T32A cart:
1. Install the Master M device on the cart.
2. Fix the device to the cart with two screws in the front (M5x12).
The T32A cart must be in horizontal position during welding.
© Kemppi
15
1922130 / 2313
