MasterTig 235ACDC, 325DC, 335ACDC
Operating manual - EN
2. Turn on the Wireless remote in the control panel settings. For MTP23X and MTP33X control panels, refer to
MTP23X/33X "Settings" on page32 and for MTP35X control panel, refer to MTP35X "Settings view" on page46.
3. Keeping the wireless remote close to the power source, long press (3 sec.) the wireless remote pairing button
on the remote.
4. Once connected, the blue LED on the left of the connection button is lit. The green LED blinks when the battery
is low.
5. To enable remote operation, select Remote mode in the control panel settings.
Remote control with cable (HR43, FR43)
1. Connect the remote control cable to the power source.
Wireless foot pedal (FR45)
Refer to the (+) and (-) signs on the battery holder and in the remote for the correct positioning of batteries.
© Kemppi
19/77 1920900 / 1939
