MasterTig 235ACDC, 325DC, 335ACDC
Operating manual - EN
6.4 Cooling unit MasterTig Cooler M
MASTERTIG COOLER M
Feature Description Value
Connection voltage U
1
50/60 Hz
220...460 V AC, 1~/3~
Maximum rated supply current I
1max
1.0 A
Rated cooling power at 1 l/min
0.9 kW
Cooling power at 1.6 l/min
1.0 kW
Recommended coolant
MPG 4456 (Kemppi mixture)
Coolant pressure (max)
0.4 MPa
Tank volume
3.0 l
Operating temperature range *
-20 ... +40 °C
Storage temperature range
-20 ... +60 °C
EMC class
A
Degree of protection **
IP23S
External dimensions L x W x H
615 x 206 x 268 mm
Weight without accessories
12.5 kg
Standards
IEC 60974-2
IEC 60974-10
* With recommended coolant
** When mounted
