MasterTig 235ACDC, 325DC, 335ACDC
Operating manual - EN
2.1 Installing mains plug
Only an authorized electrician is allowed to install the mains cable and plug.
Do not connect the machine to the mains before the installation is complete.
Install the 3-phase plug according to the MasterTig power source and site requirements. In the 1-phase power
source (MasterTig 235ACDC) the plug is pre-installed. Refer also to "Technical data" on page59 for power source spe-
cific technical information.
2.2 Installing control panel
Tools:
• Screwdriver, Torx head (T20).
1. Connect the control panel’s cable and mount the control panel in place:
>> Insert the top of the panel in the slot first, and then lower the bottom of the panel down.
>> Push the bottom of the panel firmly so that it locks in place.
© Kemppi
9/77 1920900 / 1939
