MasterTig 235ACDC, 325DC, 335ACDC
Operating manual - EN
>> Pairing status is shown as the settings value.
TIG settings:
Balance limit min: -99 ... 0, step 1 (Default =-60)
Balance limit max: 0 ... +20. step 1 (Default = 0)
Lift TIG current: 5 A ... 40 A / Auto, step 1 A (Default = Auto = 10 A)
HF spark force: 50 % ... 110 %, step 1 % (Default = 100 %)
Positive ignition current: 30 % ... 150 % / Auto, step 1 % (Default = Auto)
Positive ignition time: 0 ms ... 50 ms / Auto, step 10 ms (Default = Auto)
Negative ignition current (ACDC): 100 % ... 300 % / Auto, Step 1 % (Default = Auto)
Ignition current (DC): 100 % ... 300 % / Auto, step 1 % (Default = Auto)
Negative ignition time (ACDC): 0 ms ... 950 ms / Auto, step 10 ms (Default = Auto)
Ignition time (DC): 0 ms ... 950 ms / Auto, step 10 ms (Default = Auto)
Slight upslope: OFF / ON (Default = OFF)
Startup level:5 % ... 40 %, step 1 % (Default = 10 %)
Downslope cut level: 5 % ... 40 %, step 1 % (Default = 10 %)
2T downslope cut: OFF / ON (Default = OFF)
Nonlinear downslope: 0 % ... 50 %, step 1 % (Default = 0 %)
Current freezing: OFF / ON (Default = OFF)
TIG antifreeze: OFF / ON (Default = OFF)
AC phase swap current: 5 A ... 20 A / Auto
MMA settings:
Welding current: Min/Max = Normal welding current limits
Hot start: -10 ... +10, step 1 (Default = 0)
Arc force: -10 ... +10, step 1 (Default = 0)
MMA antifreeze: OFF / ON (Default = OFF)
VRD mode: OFF / ON (Default = OFF)
>> This setting can be locked so that the user cannot change it. In the equipment models where the VRD
mode is locked permanently to ON (e.g. AU model), the VRD option is still visible in the settings, but it can-
not be changed.
System settings:
Gas test: Gas test time:0 s ... 60 s, step 1 s (Default = 20 s)
>> Activating this starts the gas test with default time. Time can be changed by turning the control knob. Gas
test can be stopped by pressing the control knob again.
Water cooler: OFF / Auto / ON (Default = Auto)
Cooler flow watch:OFF / ON (Default = ON)
Brightness:10 % ... 100 %, step 1 % (Default = 100 %)
Weld data time:1 s ... 10 s, step 1 s (Default = 5 s)
Screen saver: Default = Kemppi logo
© Kemppi
47/77 1920900 / 1939
