Kemppi MasterTig 235ACDC GM User Manual

MasterTig 235ACDC, 325DC, 335ACDC
Operating manual - EN
MASTERTIG 325DC 325DC G 325DC GM
Feature Description Value
Arc-on signal for relay
24 V / 50 mA 24 V / 50 mA 24 V / 50 mA
Voltage supply for cooling
unit
U
cu
380...460 V 380...460 V 220...460 V
Recommended generator
power (min)
S
gen
20 kVA 20 kVA 20 kVA
Wireless communication
type:
- Control panels MTP23X,
MTP33X, MTP35X
(2
- Remote controls HR45,
FR45
(2
Transmitter fre-
quency and
power
2.4 GHz Bluetooth,
2400-2483.5 MHz, 10
dBm
2.4 GHz Bluetooth,
2400-2483.5 MHz, 10
dBm
2.4 GHz Bluetooth,
2400-2483.5 MHz, 10
dBm
Wired communication type Remote
Analog Analog Analog
CAN BUS
Kemppi Remote-Bus Kemppi Remote-Bus Kemppi Remote-Bus
Arc striking voltage
5...11 kV 5...11 kV 5...11 kV
Stick electrode diameters ø mm
1.6...6.0 mm 1.6...6.0 mm 1.6...6.0 mm
Standards
IEC 60974-1,-3,-10
IEC 61000-3-12
AS 60974.1-2006
(1
GB 15579.1
IEC 60974-1,-3,-10
IEC 61000-3-12
AS 60974.1-2006
(1
GB 15579.1
IEC 60974-1,-3,-10
IEC 61000-3-12
AS 60974.1-2006
(1
GB 15579.1
1)
Applies only to the power source model versions where the Voltage Reduction Device (VRD) function is locked
on.
2)
NO: These devices are not allowed to be used within a 20 km radius of the centre of Ny-Ålesund at Svalbard, Nor-
way. This restriction applies to any 2-32 GHz transmitter operation.
© Kemppi
62/77 1920900 / 1939
