GENERAL INFORMATION
SERVICE MANUAL
ENGLISH
Razor™ 20 / 20T 9097065000(2)2009-06
7
TECHNICAL DATA
Modello
Razor™ 20
(1 brush/padholder,
without drive system)
Razor™ 20T
(1 brush/padholder,
with drive system)
Machine height 41.7 in (1.058,5 mm)
Solution tank capacity 11.1 USgal (42 litri)
Recovery water tank capacity 11.1 USgal (42 litri)
0 ÷ 0.4 gpm (0 ÷ 1,6 lt/min)
Solution/clean water autonomy 0,3 gpm (1,1 lt/min) ~ 36 min Media/Average
Front wheel diameter 7,9 in (200 mm)
130 psi (0.9 N/mm
2
)
435.1 psi (3 N/mm
2
)
Rear wheel diameter 3.9 in (100 mm)
Vacuum system motor power 0.44 hp (330 W)
Drive system motor power — 0.27 hp (200 W)
Drive speed (variable) —
da 0 a 2.8 mph
(da 0 a 4,5 km/h)
Max gradeability — 16% - 9°
Working gradeability 2 % - 1°
Sound pressure level (at the operator’s position) (ISO 11201, ISO 4871) (LpA) 66 dB(A) ± 3dB(A)
Sound pressure level (to the machine) (ISO 3744, ISO 4871) (LwA) 84 dB(A)
Vibration level at the operator’s arms (ISO 5349-1) < 98,4 in/ s
2
(< 2,5 m/s
2
)
Standard batteries WET (2 x 12 V) 24V 105Ah
Standard batteries autonomy ~ 3,2h ~ 2,6h
Battery compartment size (width x length x height) 13.8 x 13.8 x 11.8 in (350 x 350 x 300 mm)
Vacuum system circuit capacity 41.5 in H
2
O (1.055 mm H
2
O)
Cleaning width 20.9 in (530 mm)
Squeegee width 29.9 in (760 mm)
Machine maximum length 48.3 in (1.228 mm)
Machine width without squeegee 21.3 in (540,8 mm)
Brush diameter 20.9 in (530 mm)
Deck right/left offset 3/- in (75,9/- mm)
Brush distance from the ground (when lifted) 2,36 in (60,1 mm)
Weight without batteries and with empty tanks 178.6 lbs (81 kg) 211.6 lbs (96 kg)
Maximum weight with batteries and full tanks 469.6 lbs (213 kg) 504.5 lbs (229 kg)
Brush motor power 0.64 hp (480 W)
Brush speed 153 rpm
Brush/pad-holder pressure with extra-pressure function turned off 45.2 lbs (20,5 kg)
Brush/pad-holder pressure with extra-pressure function turned on (Optional) - 66,1 lbs (30 kg)
Battery maximum size
Brush and squeegee maximum size
Full solution tank
Optional equipment installed
Wheel weight checked
Each wheel print checked on cement
Result expressed as maximum value for both front and rear wheels
