R-SE9T/ DP-SE9/ X-SE9 (En)
17
Preparation section Basic section Application section Know ledge sections
Operation of remote control unit
Operation
Loading batteries
2 Insert batteries. 3 Close the cover.
÷ When pressing more than one remote control keys
successively, press the keys securely by leaving an
interval of 1 second or more between keys.
After plugging the power cord of this unit, press
the on/ standby key of the remote control unit to
turn the power of the system ON. When the
power is turned ON, press the key of the function
to be operated.
1.The provided batteries are intended for use in operation checking, and their service life may be short.
2.When the remote controllable distance becomes short, replace both of the batteries with new ones.
3.If direct sunlight or the light of a high- frequency fluorescent lamp (inverter type, etc.) is incident to the remote
sensor, malfunction may occur. In such a case, change the installation position to avoid malfunction.
1 Remove the cover.
÷ Insert two R6 (“ AA” -size) batteries following the polarity indications.
Operation of remote control unit
Notes
Notes
Operating range (approx.)
Remote
sensor
Model: RC-SE9(E)
Infrared ray system
30° 30°
6 m
