5-5 Objects Usable by DL-EP1
5-24
Assembly Object
5
Appendix
- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (GT2) -
List of general and additional statuses returned to each service
Name
General
Status
Additional
(Extended)
Status
Description
Get_Attribute_Single
00H - The service has ended normally.
05H - The designated instance ID does not exist.
14H - The designated attribute ID does not exist.
Set_Attribute_Single
00H - The service has ended normally.
05H - The designated instance ID does not exist.
08H -
The instance ID whose attribute is read (R)
was designated.
0CH -
An attempt was made to execute the
service for the instance during cyclic
communication.
0EH -
The designated attribute ID cannot be
written.
14H - The designated attribute ID does not exist.
15H -
An attempt was made to write the data
larger than the defined size.
Others 08H - The designated service is not supported.
