- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (GT2) -
Connection and Configuration
This section describes procedures from installing the DL-EP1 and
sensor amplifiers to configuring communication.
2-1 Procedures from Installation before Using the DL-EP1 to
Configuration...........................................................2-2
2-2 Installation and Connection to Sensor Amplifiers ... 2-3
2-3 Wiring ................................................................. 2-8
2-4 Configuring Communication with the DL-EP1 .. 2-10
2-5 Configuring Communication with the Scanner . 2-13
