Keyence DL-EP1 User Manual

5-5 Objects Usable by DL-EP1
5-22
Message Router Object
5
Appendix
- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (GT2) -
This object provides connection points for message communication.
 Class
z Class service
This object supports Get_Attribute_Single (0EH).
z Class attribute (instance ID: 00H)
 Instance
z Instance service
This object supports Get_Attribute_Single (0EH).
z Instance attribute (instance ID: 01H)
Message Router Object (Class ID: 02H)
Attribute ID Name Description Attribute
Data
Typ e
Parameter
Range
01H Revision Object revision R UINT 0001H
02H Max Instance
Maximum instance
number
R UINT 0001H
03H
Number of
Instances
Number of instances in
generated object
R UINT 0001H
06H
Maximum ID
Number Class
Attributes
Maximum attribute ID of
class attribute
R UINT 0007H
07H
Maximum ID
Number
Instance
Attributes
Maximum attribute ID of
instance attribute
R UINT 0002H
Attribute ID Name Description Attribute
Data
Typ e
Parameter
Range
01H
Object_list
Supported
object list
R
Structure -
Number
Number of classes
supported in class array
UINT 0007H
Classes Class ID list
UNIT-
type
array
0001H
0002H
0004H
0006H
00F5H
00F6H
0067H
02H
Number
Available
Maximum number of
connections
R UINT 0040H
