Keyence DL-EP1 User Manual

5-5 Objects Usable by DL-EP1
5-21
Identity Object
5
Appendix
- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (GT2) -
Reset service
The Reset service is a CIP standard function used to emulate the same operations as
power restart as much as possible. When it accepts this service, the DL-EP1 stops
each function, interrupts communication, and reads the settings again. The Reset
service is used as a restart request for reflecting changed parameters (e.g., IP
address, Ethernet communication speed, etc.).
Execute this service by designating 01H as the Instance ID of the Identity object.
• The commands received during Reset processing may be discarded.
• The response for the Reset service is returned before the DL-EP1 starts
reset processing.
 List of general and additional statuses returned to each service
Service Code Service Name Service Data (1 Byte)
05H Reset
00H: Emulates power reset. (Initial value)
01H: Restores the default settings and emulates power reset.
For details on the default settings, refer to "Default
Settings" (Page 5-5).
• If the DL-EP1 receives the Reset service when 02H or
higher is set, 03H (Invalid parameter value) is returned as
the CIP error code.
Point
Service
General
Status
Additional
(Extended)
Status
Description
Get_Attributes_
All
00H - The service has ended normally.
05H - The designated instance ID does not exist.
Reset
00H - The service has ended normally.
03H - The designated reset method is incorrect.
05H - The designated instance ID does not exist.
Get_Attribute_
Single
00H - The service has ended normally.
05H - The designated instance ID does not exist.
14H - The designated attribute ID does not exist.
Others 08H - The designated service is not supported.
