5-5 Objects Usable by DL-EP1
5-28
TCP/IP Interface Object
5
Appendix
- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (GT2) -
z Instance attributes (instance ID: 1)
Attribute ID Name Description Attribute
Data
Typ e
Parameter
Range
01H Status Interface status R
DWORD Reference 1
02H
Configuration
Capability
Method for acquiring
initial IP address
R
DWORD Reference 2
03H
Configuration
Control
Method in which the device
acquires initialization at
start-up
R/W DWORD Reference 3
04H
Physical
Link Object
Path to physical link
object
R
Structure -
Path size Path size (bytes) UINT 0004H
Path
Segment for identifying
physical link object
Padded
EPATH
20F62401H
05H
Interface
Configuration
TCP/IP network interface
setting
R/W
Structure -
IP Address
Device IP address
(IP address)
UDINT
Setting value
*1
Network Mask
Device network mask
(Subnet mask)
UDINT
Setting value
*1
Gateway
Address
Default gateway address
(Gateway address)
UDINT
Setting value
*1
Name Server
Primary name server
(DNS server)
UDINT
Setting value
*1
Name Server 2
Secondary name server
(reserved)
UDINT
Setting value
*1
Domain Name
Default domain name
(reserved)
STRING
" "(character
string can be
set)
06H Host Name Host name R/W
STRING
" "(character
string can be
set)
08H TTL Value Multicast TTL R/W USINT
1 (1 to 255)
setting value1
*1
09H
Mcast Config Multicast address setting
R/W
Structure -
Alloc Control
Multicast address setting
function (multicast
allocation method)
USINT
0: Automatic
allocation
1:User-
designated
allocation
Reserved Reserved USINT 00H
Num Mcast
Number of multicast
addresses
(Number of multicast
addresses)
UINT
For automatic
allocation:
0020H
For user-
designated
allocation: 1 to
256
*1
Mcast Start
Addr
Start multicast address
(Allocation start multicast
address)
UDINT
For automatic
allocation:
*2
For user-
designated
allocation:
Setting value
*1
