3-3 Cyclic communication
3-10
3
Communicating with the GT2 Series
Output 5
(LL)
26 ID08 . . . . . ID01
27
Reserved for
system
ID15 . . . . . ID09
External
Input
Response 1
(Preset)
28 ID08 . . . . . ID01
29
Reserved for
system
ID15 . . . . . ID09
External
Input
Response 2
(Timing)
30 ID08 . . . . . ID01
31
Reserved for
system
ID15 . . . . . ID09
External
Input
Response 3
(Preset)
32 ID08 . . . . . ID01
33
Reserved for
system
ID15 . . . . . ID09
External
Input
Response 4
(Error
Clear)
34 ID08 . . . . . ID01
35
Reserved for
system
ID15 . . . . . ID09
External
Input
Response 5
(Unassigned)
36 ID08 . . . . . ID01
37
Reserved for
system
ID15 . . . . . ID09
Error
ID Number
40
Current Error ID Number (16-bit unsigned integer)
41
Error
Code
42
Current Error Code (16-bit unsigned integer)
43
Warning
ID Number
44
Current Warning ID Number (16-bit unsigned integer)
45
Warning
Code
46
Current Warning Code (16-bit unsigned integer)
47
Current
Value 0
(
Comparator
Value (P.V.)
or Raw
Value (R.V.))
48
ID Number 1 (Current Value 0) (32-bit signed integer)
49
50
51
::
104
ID Number 15 (Current Value 0) (32-bit signed integer)
105
106
107
Current
Value 1
(
Unassigned )
108
ID Number 1 (Current Value 1) (32-bit signed integer)
109
110
111
::
164
ID Number 15 (Current Value 1) (32-bit signed integer)
165
166
167
Name
Address
(Byte)
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
