- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (GT2) -
3-4 Message Communication
3-32
3
Communicating with the GT2 Series
・Lock setting
● Responses
The responses made when each service is used are as follows:
(1) Parameter read: : Service code 0EH
(2) Parameter write: : Service code 10H
(3) Operation command: : Service code 4BH
(4) Batch lock setting: : Service code 4CH
(5) Read of number of decimal places: : Service code 4DH
Setting Description
0
Does not execute lock.
1
Executes full key lock (inhibition of operations other than basic screen
display switching).
2
Executes key lock (inhibition of operations other than basic screen display
switching and [RESET] button).
General
Status
Command Type
Description
(1) (2) (3) (4) (5)
00H {{{{{Normal end
05H {{{{{The instance ID is out of range.
08H - - {{ -
The designated instance ID does not support this service or
cannot be executed.
09H - - - { - The written data is out of range.
0CH - {{ --
• Parameter write was executed for the function controlled
by cyclic communication.
• An attempt to execute the operation command has failed.
Check if the sensor amplifier can execute the operation
command.
0EH - { ---
• An attempt was made to write data to the attribute ID that
cannot be written or to the attribute ID that is in the
unwritable status.
• The written data is out of range.
10H { ----
An attempt was made to read data from the attribute ID that
cannot be read or from the attribute ID that is in the
unreadable status.
13H { - { -
The service data size is less than the defined size.
The defined data size is stored in the additional status.
14H {{{ - { The attribute ID is out of range.
16H {{{ - {
The sensor amplifier corresponding to the designated
instance ID is not connected.
1FH {{{{{
• This service is supported by the designated instance ID
but cannot be used by the designated attribute ID.
(Additional status: C350H)
• In the current mode, the designated setting cannot be
written into the parameter.
(Additional status: C351H)
• The DL-EP1 is now initializing communication. (Additional
status: C352H)
FEH {{{{{System error. Contact your nearest KEYENCE office.
