Keysight Technologies B1505A Handbook

21
For disconnecting the interlock cable, hold the metal part and then pull the
connector by turning it.
Step 6
Step 3
Step 2
Step 4
Step 1
Step 5
Figure 2-7. Breakdown of the cable connection for 20 A configuration.
Pressing and turn
Pulling and turn
For connecting: For disconnecting:
Figure 2-8. Interlock connection.
