94
tects the Y axis value of the measurement curve at the specified X axis
point.
Step 19. Press Display Setup tab.
You can set the X-Y Graph, List Display and the Parameters of the meas-
urement results in this page.
Step 20. The X, Y1, Y2 and so on to maximum Y8 axis can be defined as X-Y graph
display.
Log or Linear scale and the Min. and the Max. scale parameters are set.
Step 21. List Display sets the measurement parameters that are shown in the List
area of Display Graph window.
Step 22. Parameters field sets the display of extracted parameters.
In the example setup, Vce_sat and Vbe_sat are defined in the Auto Analy-
sis and Function Setup tabs. (Step 13 to step 18)
Step 23. Make sure the device is properly selected as shown in the "Device used in
the example" part or your selection.
Close the lid of N1259A test fixture.
Start the measurement. (Click the Single button )
Step 24. The graph window pops up, and the measurement starts.
Step 25. You can see the Vcollector-Icollector curve on Y1 axis and Vbase (Y2 axis)
graph in figure 3-36.
The marker is automatically moved to the Icollector value (X axis) specified
in the Marker function of Auto Analysis Setup, and the corresponding
Vce_sat and Vbe_sat are displayed on the Parameter field.
