Performance Tests 2
Keysight E4416A/E4417A Power Meters Service Guide 45
9 Set the DC calibrator as follows:
– SET VALUE: 0 (ZERO)
–FUNCTION: DC
–OUTPUT: OFF
10 Set the filter length:
– Press .
– Highlight the Filter parameter using the up/down arrow keys.
– Scroll through the Filter values by pressing . Select a value of
MAN.
– Highlight the filter length using the forward arrow key. Press . The
Filter Length pop-up window is displayed. Set the filter length to 512.
– Press .
11 Zero the power meter:
Press
, . Wait approximately 10 seconds for the wait symbol to
disappear.
12 Set the DC calibrator output to 144.93 mV, and set the output switch to '+'.
13 Calibrate the power meter:
Press
, .
14 Set the DC calibrator output to the values shown in Table 2-4. For each
setting, set the filter length of the power meter to the carbon-dating value,
and verify that the power meter reading is within the limits shown. Refer to
step 10 for details on how to setup the filter length.
