50 Keysight E5061B Network Analyzers
Troubleshooting
Performance Test failure Troubleshooting
2-
###: Most suspicious assembly
##: Suspicious assembly
#: Possible faulty assembly
15 Magnitude ratio/phase frequency
response test (Opt 3L5)
#####
16 Trace noise test (Opt 3L5) ## ### #
17 DC measurement accuracy test
(Opt 3L5)
### ###
Table 2-9 Performance Test failure Troubleshooting information (Option
115/117/135/137/215/217/235/237)
Test Num.
First failed test Probable faulty board assembly or
parts
A11 Source
Module
A3/A4 Receiver
Module
1 Frequency accuracy test ### #
2 RF output level accuracy test ### #
3 RF output level linearity test ### #
4 Crosstalk & system dynamic range
test
## ###
5 Noise Floor Test ## ###
6Trace Noise Test # ###
7 Dynamic Accuracy Test
8Compression ###
9 IF linearity at 1.195GHz ###
10 IF linearity at LF ###
11 Uncorrected System Performance
test
####
Table 2-8 Performance Test failure Troubleshooting information (Option 3L5)
Test Num.
First failed test Probable faulty board assembly or parts
A1/A11
Source
Module
A2 Receiver
Module
A9 LF
Source Bias
Module
To Next Page
