Keysight E5061B Network Analyzers 49
Troubleshooting
Performance Test failure Troubleshooting
Table 2-8 and Table 2-9 represents the relationships between the failed test
and probable faulty assembly. If the performance test failure cannot be
removed by a proper adjustment, replace the assembly shown in this table.
When Crosstalk, System dynamic range or Uncorrected system
performance test fails, check first whether the connections of the RF
semi-rigid cables between the suspicious assembly and others are tight or
loose. Also check for possible disconnection (impairment) of the cables
and connectors.
Table 2-8 Performance Test failure Troubleshooting information (Option 3L5)
Test Num.
First failed test Probable faulty board assembly or parts
A1/A11
Source
Module
A2 Receiver
Module
A9 LF
Source Bias
Module
1 Frequency accuracy test ### # #
2 RF output level accuracy and
flatness test
### # #
3 RF output level linearity test ### # #
4Trace noise test ## ### #
5 Crosstalk & system Dynamic Range
test
## ### #
6 Dynamic accuracy test # ### #
7 Uncorrected system performance
test
## ### #
8 LF output level accuracy& flatness
test (Opt 3L5)
## ###
9 LF output level linearity test (Opt
3L5)
## ###
10 DC bias accuracy test (Opt 3L5) # ###
11 Crosstalk & noise level test (Opt
3L5)
#####
12 Input impedance test (Opt 3L5) ###
13 Absolute amplitude accuracy test
(Opt 3L5)
#####
14 Magnitude ratio/phase dynamic
accuracy test (Opt 3L5)
#####
To Next Page
