To view the available folder and files in the directory, press Showing Folder or Showing All. Press Select once you
have specified the path or Cancel to abort.
Press File Name and use the keyboard to enter the filename in the File Name field. Press Done to save and Cancel
to abort.
Filename
Select the Filename to specify a filename in which to save the datalog. Data will be logged to this filename the next
time the Data Logger runs. If you do not specify a filename, the data will be logged to default_log.dlog, which is
overwritten each time the Data Logger runs.
Export the data
To export a data log that has been saved in the USB drive, you must first load the saved file into the data log-
ger view.
Press Export File to export the data that is currently in the instrument's data log viewer to file. The exported data is in
.csv format.
For details on how to specify the save location and filename, refer to Save the Data Log.
Keysight EL30000 Series User's Guide 113
