Parameter Available Key
Settings
Description
Trigger Source Key, IO, or Rmt Sets the trigger source for the system.
Default is Key.
Action required:
Press Trig Src to toggle between Key, IO, and Rmt.
Key (List Run/Stop Key) Selects the Run Stopped softkey as a trigger
source.
IO (DIO Trigger In) Selects any configured digital IO (with Trigger
Input function) as a trigger source
Rmt (Remote Command) Selects a remote interface command as a trigger
source.
Trigger Delay 0 to 0.255 s Sets the trigger delay in seconds.
Default is 0 s.
Step 2 – Run the input sequence
In this example, the load operation is in CV mode.
– Set V
1
, pulse width, trigger delay and repeat count accordingly: Use the navigation keys to select the field; use the
numeric entry keys to enter the value. The value is set when you press [Enter].
– Set Trigger Source to Key. Press Trig Src Key.
– Press the color-coded [On] key to enable the selected input.
– Press Run to start the sequence operation. To abort the operation, press Stop.
– Press Back to exit and return to the previous menu.
Keysight EL30000 Series User's Guide 97
