16 Keysight Infiniium 9000 Series Oscilloscopes User’s Guide
1 Setting Up the Oscilloscope
Connecting Accessories and Cables
A mouse and keyboard can be plugged into either a USB port or a PS2 port. There
are several USB connectors on the front panel or the side panel that can be used.
When using the PS2 port, the keyboard must be plugged in prior to turning on
power to the oscilloscope.
Connect your LAN cable to the RJ-45 connector on the side panel of the
oscilloscope.
Side panel USB connectors can be used for any USB devices. There are also three
USB connectors in the lower right corner of the front panel.
If you have a parallel printer, you will need a parallel printer cable. Connect the
cable to the parallel port on the side panel of the oscilloscope.
If you have a serial printer, you will need a 9-pin to 25-pin serial printer cable.
Some printers may require other cable configurations, but the oscilloscope has a
9-pin serial connector. Connect the cable into the RS-232 port.
After you have connected to the LAN card, you must set up the network. Exit the oscilloscope
application before you start setting up your network.
If you do not know how to set up a network in the Windows 7 operating system, see your
network administrator or use the Windows 7 operating system’s online help.
