Keysight Technologies Infiniium 9000 Series User Manual

28 Keysight Infiniium 9000 Series Oscilloscopes User’s Guide
2 Using the Oscilloscope
Front Panel Controls (Keys and Knobs) Overview
The Infiniium 9000 Series oscilloscope front panel gives you direct access to the
functions needed to perform the most common measurements, using a traditional
oscilloscope interface. Knobs and keys let you directly set vertical and horizontal
parameters. The front panel also has a set of LED indicators; by using these and
the display, you see the oscilloscope’s configuration at a glance.
The oscilloscope uses color consistently throughout the front panel and user
interface. For example, the color of the knob for channel 1 is the same color as the
waveform for channel 1. All the configuration items and values related to channel
1 are displayed in the same color.
Figure 7 Infiniium 9000 Series oscilloscope front panel
Run/Stop control section
Horizontal controls
(time/div, position, etc.)
Trigger controls
Turn digital channels on/
Turn serial decode on/off
Color coded controls for
each analog oscilloscope
channel
Selection knob (push to toggle selection)
