112 Keysight CXG, EXG, and MXG X-Series Signal Generators Service Guide
Service and Utility Menus
Utility Service Menu
Front Panel Tests
The Front Panel Tests verify the functionality of multiple front panel operations,
all of which should be verified after the instrument front panel has been
repaired or replaced. These operations include:
1. LCD pixel test
2. Front panel indicator LED test
3. Front panel hard and soft key test
4. RPG test
To access the Front Panel Tests menu as shown in Figure 5-13, press Utility,
Instrument Info.
Table 5-1 Possible Installed Assembly Part Numbers
Assembly Part #
N5166B N5171B N5172B N5173B N5181B N5182B N5183B
RF
a
N5180-60203 X X
N5180-60239 X X
N5180-60279 X X X
N5180-60173 X
N5180-60150 X X
N5180-60238 X X
N5180-60278 X X
N5180-60151 X
BB
a
N5180-60145 X X
N5180-60280 X X X
CPU 0950-2870 X X X X X X
0950-3295 X X X X X X X
MW
a
N5180-60172 X X
RT App
b
XX
Front Panel N5180-60158 X X X X X X X
a. If the installed assembly is a refurbished assembly it could be a -69xxx part number
instead of -60xxx.
b. RT App is only present with option 660 and does not report a part number or serial
number.
